4.5x9m Marine Inflatable Fender Black Rubber Boat Bumpers For Ships Shipyards

Product Categories

QINGDAO HAOZHIYUE AIRBAG CO.,LTD

Contact Now

4.5x9m Marine Inflatable Fender Black Rubber Boat Bumpers For Ships Shipyards

Name: 45x9m Marine Inflatable Fender Black Rubber Boat Bumpers For Ships Shipyards
Brand: HAOZHIYUE
Price: 1 USD

Best 4.5x9m Marine Inflatable Fender Black Rubber Boat Bumpers For Ships Shipyards wholesale

Brand Name : HAOZHIYUE

Model Number : HZY-50

Certification : CCS/BV/LR/IRS/IACS

Place of Origin : China

MOQ : 1pc

Supply Ability : 30pcs/month

Delivery Time : 5~8 working days

Packaging Details : Nude,pallets or according to request

Material : Natural rubber/ Synthetic tire cord layers

Color : Black

Size : 4500x9000 4.5x9.0m

Warranty : 2 years

Lifespan : More than 10 years

Application : ship, hydroponics, bathroom, Floating and berthing(ship to ship or ship to dock),

Usage : boat rubber fender, Protect Shipboard, waterproof, anti-explosion rubber fender, Protect Boat

Contact Now

Inflatable Marine Rubber Floating Fender for Ships Boats Shipyards

Product Overview

4.5x9m Marine Inflatable Fender Black Rubber Boat Bumpers For Ships Shipyards

Floating pneumatic marine rubber fenders are known as Yokohama fenders or Yokohama-type pneumatic fenders. Floating pneumatic rubber fenders are made of the synthetic-cord-reinforced rubber sheet with compressed air inside. The insider air can enable it to float on the water and work as a shock absorbed between two ships (ship-to-ship), or between ships and berthing structures when they come alongside each other on the water. All Haozhiyue Marine Yokohama type floating pneumatic rubber fenders are manufactured and tested fully compliant with ISO 17357

1.Outer Rubber
 Cover outside on the ball of rubber layer, which is used to protect skeleton material and inner rubber ball from damage of external force.
 2.Cord layers
 Reinforced cord rubber layer is composed of winding synthetic cord layer, it is mainly used for maintain the internal air pressure.
 3. Inner Rubber
 On the ball inside the rubber layer, which is used to prevent air leakage and control the ball pressure.
 4. End Flange
 The metal parts at both ends of fender, which can be fitted with charging valve and safety valve.

Our Advantages

Why choose HAOZHIYUE pneumatic rubber fender?

1.Learder since 1992, with more than 20 years produce experience;

2.Best quality with 3 years guarantee period;

3.Comply with ISO17357:2002;

4.Certificates BV,CCS,LR,IRS etc available;

5.Customized different dimention according to requirements;

6.Lifespan more than 10 years;

7.Different dimension stocks, the delivery time can be within 3 days;

8.Can be deflated in transit.

9.Long time good after-sale service;

10.Professional engineer recommend suitable dimension and quantity of rubber fender.

Specification

Specification and Performance of pneumatic marine rubber fender

*Specification (D×L)mm**	Initial pressure 50kPa		Initial pressure 80kPa
*Specification (D×L)mm**	Reaction force (kN)	Energy absorption (KJ)	Reaction force (kN)	Energy absorption (KJ)
0.5×1.0	64	6	85	8
0.6×1.0	74	8	98	11
0.7×1.5	137	17	180	24
1.0×1.5	182	32	239	45
1.0×2.0	257	45	338	63
1.2×2.0	297	63	390	88
1.35×2.5	427	102	561	142
1.5×3.0	597	153	761	214
1.7×3.0	639	191	840	267
2.0×3.5	875	308	1150	430
2.5×4.0	1381	663	1815	925
2.5×5.5	2019	943	2653	1317
3.3×4.5	1884	1175	2476	1640
3.3×6.5	3015	1814	3961	2532
4.5x9.0	5747	4752	7551	6633

Yokohama Pneumatic rubber fender are available from 500X1000mm to 3300X6500mm, including all the standard and no-standard specifications.

All the relevant metal accessories of pneuamtic fenders, include shackles, towing rings, swivels, chain net, are made of stainless steel, and H.D.G. which are resistant for sea water corrosion.

---Accessories(All accessories is stainless steel or hot dip galvanizing):

---BV Inspection:

4.5x9m Marine Inflatable Fender Black Rubber Boat Bumpers For Ships Shipyards

---Productive Process:

Certifications

Delivery

Certificate of CCS,ABS,GL.BV,DNV etc is available<<<<

FAQ

1. Q:What’s the guarantee for your products?

A:Guarantee period for our product is 3 years, during this period, except man-made damage, we will repair or exchange new one for free.

2. Q: Do you have stocks? In which size?

A:Yes, we have some normal size in stocks,for example dia1.2m,dia1.5m,dia2.5m,other size pls confirm with our company directly.

3. Q:Are you manufacturer or trading company?

A: We are manufacturer in this field for more than 20 years, with rich produce experience.

4. Q:We don’t know which size is suitable,can you help me?

A:No problem,pls tell us information about your ship, our engineer will recommend suitable size for you.

5. Q:What’s the delivery time?

A: Usually within 3 days after receive payment.

6. Q:What’s your payment term?

A:T/T or L/C at sight

7. Q: What’s your MOQ?

A: 1 PC.

8.Q: What’s the material of your products ?

A: the main raw materials are natural rubber, synthetic-tyre-cord fabric and customized hardwares, etc.

9.Q: Is OEM service available ?

A: yes
